Industrial 1 inch Hidden Island Support Bracket

Sale price Regular price $83.95
.
Size
 More payment options
Free Ground Shipping

Need Counter Top Supports for a Large Overhang?



Heavy countertop overhangs are the Industrial 1 inch Hidden Island Support Bracket’s® specialty and it can support all stone types including Granite, Quartz, Marble, and Concrete.

The Industrial 1 inch Hidden Island Support Bracket® is used when there is no knee wall or when you have an oversized overhang requiring the best on the market. This is THE perfect concealed support for countertop overhangs on a kitchen island or breakfast bar. Give yourself or your customer the peace of mind they deserve by having the strongest kitchen island support bracket on the market; the Industrial 1 inch Hidden Island Support Bracket®

This bracket is designed to attach to the inside of the front wall of the cabinet and will extend through the cabinet.

Dimensions:



Length: [You Choose]



Width: 2-1/2 inches



Thickness: 1 inch


How to Determine What Size Bracket?



The bracket will be mounted to the inside of the cabinet. Start by measuring your cabinet from the inside front wall (where the doors are) to the opposite side of the cabinet (for our example we are saying this measurement is 22 inches). Next, take your measurement you just did (22 inches) and add the inches of the overhang of the countertop (for example 15 inches), then minus 3 inches (to stay away from the outer edge of the countertop). This example would give you a total of 34 inches (22 +15 - 3= 34) - you would then need to order a 34 inch Hidden Island Support Bracket



Hidden Island Industrial Support Bracket® Features:

  • Hardware Included
  • Virtually invisible giving your island the appearance of floating.
  • Non-intrusive. No corbels needed. No knee-knocking.
  • The flange is welded onto the support bracket.
  • An economical way to protect your countertop investment.
  • Instills confidence that your countertop is supported effectively.
  • Completely open space allowing room for chairs and legs.
  • Easy to install.
  • Made of 1 inch thick by 2 ½ inches wide proprietary ribbed aluminum made here in the USA.
  • Bracket end has a beveled edge for safety.
  • Screw hole on each side of the flange.
  • Made in the USA.
  • Limited Lifetime Warranty**
  • All of our Aluminum brackets are painted with a double coat of rust inhibitor black paint.
  • Free Ground Shipping To The Lower 48 and Canada!

Helpful Information & Downloads:

  • We offer Free Ground Shipping to the lower 48 states and Canada! Shipping information will be available upon order placement.
  • For orders exceeding 20 brackets or a general breakdown of how our shipping works check out our Shipping Policy for lead time.
  • Although we have standard sizes, we can manufacture special order brackets with specifications to your request.

Have questions or need assistance? Contact our dedicated customer service team at 888-584-1112 EX 1 or email joe@originalgranitebracket.com

Individual Pricing: The price listed is for one bracket. Images showing multiple brackets are for illustration purposes only. Be sure to order the quantity needed for your project.
